Power Supply / Light Source Extension Cable
 Power Supply / Light Source Extension Cable* Power supply has a constant current lighting system and it requires power supply internal adjustment. Please make sure to use the unit with LED lighting. |
|||||||||||||
| LP-2820 | |||||||||||||
 |
Specifications - Input Voltage: 100 VAC 50 / 60 Hz (Allowed Input Range: 85 VAC - 132 VAC) - Light Quantity Adjustment: Electric Current Variable Type - Function 1. LED ON / OFF 2. Light Quantity Remote (0 VDC to +5 VDC) - Fuse: 250 VAC 1A - External Dimensions: W 60 x H 85 x D 160 (except Projection) - Weight: 0.8 kg |
||||||||||||
| LP-2820-II (2 Channels Power Supply) | |||||||||||||
 |
Specifications - Input Voltage: 100 VAC 50 / 60 Hz (Allowed Input Range: 85 VAC - 132 VAC) - Light Quantity Adjustment: Electric Current Variable Type - Function 1. LED ON / OFF 2. Light Quantity Remote (0 VDC to +5 VDC) - External Dimensions: W 100 x H 85 x D 170 (except Projection) - Weight: 1.6 kg |
||||||||||||
| LP-2820-III (Dedicated Power Supply for Shadowless Dome: HDDV26III) | |||||||||||||
|
Specifications - Input Voltage: 100 VAC 50 / 60 Hz (Allowed Input Range: 85 VAC - 132 VAC) - Light Quantity Adjustment: Electric Current Variable Type - Function 1. LED ON / OFF 2. Light Quantity Remote (0 VDC to +5 VDC)(Coaxial Drop, Independent Modulated Light for Direct or Indirect Radiation Part) - External Dimensions: W 100 x H 85 x D 170 (except Projection) - Weight: 2.4 kg |
||||||||||||
| Extension Cable for Light Source | |||||||||||||
 |
|
||||||||||||
Important Note about the Power Supply and Repair
Power supply of some products is adapted to Japanese 100V specifications. In case of using it outside of Japan, please be sure to use a voltage converter for each country/area.Also, when you need to repair the products purchased from Pulse Denshi, please send them back to us so we can offer repair cost estimates. Your local service center may not accept such repair.
